Frame

Torsion-resistant longitudinal beam chassis for high directional stability

Closed, completely welded and hot-dip galvanized steel frame profile for optimum stability

Support wheel

Reinforced automatic support wheel mounted on a separate cross member with a load capacity of 500 kg for safe parking of the trailer

Manoeuvring handle for easy handling

Superstructure

Rail bracket mounted under the loading area

Two steel ramp rails with a max. load capacity of 2900 kg / pair, length: approx. 2625 mm, width: approx. 300 mm

Winch block and hand winch with 900 kg pulling force supplied loose for safe loading

One pair of sturdy drop supports mounted at the rear

Drive-on rail anti-slip device at the rear of the vehicle

Load securing

Powder-coated side skirts in black-grey (RAL 7021) for securing the load

Lashing points in the side skirts can each be loaded with up to 400 daN (kg)

Lashing recesses can be loaded with up to 600 daN (kg) each and DEKRA certified

Loading area

Multi-bonded, anti-slip and waterproof screen printing plate (18 mm)

Electrical system

Lighting with 13-pin plug and protected rear lights for long and safe operation ft he electrical components

Cable routing in the chassis longitudinal members -> protection against external influences, therefore particularly durable
