Frame
Torsion-resistant longitudinal beam chassis for high directional stability
Closed, completely welded and hot-dip galvanized steel frame profile for optimum stability
Support wheel
Reinforced automatic support wheel mounted on a separate cross member with a load capacity of 500 kg for safe parking of the trailer
Superstructure
Sandwich panels with a wall thickness of 60 mm for optimum stability and insulation
Inner and outer layer made of galvanized and powder-coated sheet steel for robust use
Elegant exterior color in white (RAL 9001)
Insulated base (60 mm)
Double-wing rear door with rubber seal and aluminum hinges
Stainless steel espagnolette lock and door retainer
Stainless steel rear portal
Edging profiles made of anodized aluminium profiles
All-round stainless steel scuff plate on three sides (height: 200 mm)
Temperature control range from -2° C to +15° C
230 V 50 Hz mains connection
1130 m³/hour Air volume flow Evaporator
Operation with environmentally friendly CFC-free refrigerant
Electronic refrigeration controller with defrost management
Self-explanatory operating display for easy temperature setting, lockable and therefore protected against unauthorized use
Digital temperature display for easy control ft he refrigerated trailer temperature
230 volt interior lighting
Loading area
Electrical system
Lighting with 13-pin plug and protected rear lights for long and safe operation ft he electrical components
Cable routing in the longitudinal rails of the chassis -> protected from external influences and particularly durable
